9/1/05
Overtightening the lock lever
CAUTION
!
adjustment
permanently damage the locking mechanism.
COLLET NUT
COLLET
DRIVE BIT
COLLAR
LOCK LEVER
OUTPUT
ADJUSTMENT
SHAFT
SCREW
INSTALLING ABRASIVE WHEELS
Always use the arbor nut that has same
thread size as the output shaft.
1. Install abrasive wheel onto output shaft.
2. Thread
arbor
nut
provided
output shaft finger tight, depress shaft lock
and tighten wheel with the wrench provided
(Fig. 3).
Do not overtighten. Cracks
WARNING
!
in the wheel can occur if
overtightened. Use wrench provided with
tool. Other wrenches may promote
overtightening.
MAKING A CUT
1. Make sure material being cut is secured in
a vise or fixture before attempting to cut.
2. Keep your body positioned to either side of
the wheel, but not in line with wheel. It is
important to support the tool properly and to
position your body such as to minimize body
exposure from possible wheel binding and
recoil.
3. Grip the tool with both hands when cutting
and always be ready and able to manage the
cut.
11:04 AM
Page 18
Test the tightness of the lever after each full
screw
can
turn of the adjustment screw.
FIG. 2
WHEEL GUARD
LOCK LEVER
LOCK LEVER
WARNING
!
Depressing the shaft lock may cause wheel
to spin off or damage to attachment.
onto
SHAFT
OUTPUT
LOCK
SHAFT
Operating Instructions
4. Avoid jamming, twisting or pinching the
wheel with the workpiece or otherwise
applying excessive side pressure to the
wheel.
5. Keep guard covering between wheel and
user.
6. Make sure the guard lock lever is in the
closed position and the guard is securely
mounted to the attachment. Use the allen
wrench to adjust the guard adjustment screw.
7. Maximum cutting depth is 11/16".
-18-
GUARD
LOCK LEVER
ADJUSTMENT
SCREW
SHAFT LOCK
Do not depress shaft lock
while the tool is running.
GUARD
ABRASIVE
WHEEL
FIG. 3
ARBOR
NUT
