Functional Description and Specifications
Disconnect battery pack from tool or place the switch in the locked or
WARNING
!
off position before making any assembly, adjustments or changing
accessories. Such preventive safety measures reduce the risk of starting the tool
accidentally.
Cordless Spiral Saw™
BATTERY
RELEASE TABS
BUMP-OFF SLIDE
"ON/OFF" SWITCH
INTAKE
AIR VENTS
EXHAUST
AIR VENTS
COLLAR
RZVAC1
VACUUM ADAPTER
(Not included, available as
accessory)
DEPTH GUIDE
LOCKING
KNOB
Tool
Model number RZ18V
Voltage rating 18 V
No load speed n 30,000/min
0
BC006 charger requires 12 V DC input
NOTE: ONLY USE CHARGERS LISTED ABOVE
11:04 AM Page 10
SHAFT LOCK
COLLET NUT
DEPTH GUIDE
LOCKING
SCREW
Charger
BC003, 4, 6, BC016, BC130 & BC230
Voltage rating
Battery pack
-10-
FIG. 1
BATTERY PACK
BIT / COLLET
STORAGE
LOCK PIN
BIT / COLLET
STORAGE
REMOVABLE
HARD
AUXILIARY
CONTROL
HANDLE
WRENCH STORAGE
DEPTH GUIDE
BRACKET
LOCK LEVER
DEPTH
GUIDE
120 V 60 Hz
BAT025, BAT026
BAT180 & BAT181
