ASSEMBLY INSTRUCTIONS
7. Attach the hook (M) to the bottom center
of the big top connector (I), then insert
long middle beams (E) and short middle
beams (F) into the big top connector (I)
as shown.
8. Attach the long middle beam lower tubes
(E1) and short middle beam lower tubes
(F1) to connectors 2 (H) using long screws
(CC), flat washers (BB) and nuts (DD).
Tighten with wrench (FF) and Phillips
screwdriver.
Hardware Used
BB
M6 Flat Washer
M6 x 35 mm
CC
Long Screw
M6 Nut
DD
M6 Wrench
FF
9. Connect sloped beams (D) and sloped
beam lower tubes (D1).
