ASSEMBLY INSTRUCTIONS
O
Fig.1
P
P
C1
N
C2
A
1. Connect long crossbeam 1 (B1) and long
crossbeam 2 (B2) using bolts (AA), flat
washers (BB) and nuts (DD), and then
attach connector 2 (H) to both crossbeam
assemblies using bolts (AA), flat washers
(BB).
Repeat this step for short crossbeam 1
(C1) and short crossbeam 2 (C2). Tighten
with wrench (FF).
Hardware Used
M6 x 20 mm Bolt
AA
BB
M6 Flat Washer
M6 Nut
DD
M6 Wrench
FF
Fig.3
P
O
Fig.4
O
Fig.5
B1
A
A
1
B1
AA BB
x 16
x 24
x 8
x 2
allenandroth.com
6
Fig.2
P
O
B2
A
AA
AA
BB
BB
B2
H
BB DD
