ASSEMBLY INSTRUCTIONS
10. Insert sloped beams (D) into the
remaining spots on big top connector (I).
11. Attach the sloped beam lower tubes (D1)
to connectors 1 (G) using long screws
(CC), flat washers (BB) and nuts (DD).
Tighten with wrench (FF) and Phillips
screwdriver.
Hardware Used
BB
M6 Flat Washer
M6 x 35mm
CC
Long Screw
M6 Nut
DD
M6 Wrench
FF
12. Insert small top sloped beams (J) into
small top connector (K).
10
11
11
x 8
x 4
x 4
x 2
12
allenandroth.com
