ASSEMBLY INSTRUCTIONS
Fig.17,18
S
16. Attach four corners of large canopy (R) to
the ends of sloped beam lower tubes
(D1), then secure the pocket in the
middle of large canopy (R) to the ends of
middle beam lower tubes (E1 and F1).
Close the inner facing using
preassembled hook-and-loop fasteners.
R
Fig.16
T
Fig.19
16
D1
