ASSEMBLY INSTRUCTIONS
2. Attach ferrules (N) to the middle of crossbeam
assemblies using short screws (EE) and flat
washers (BB). Tighten with Phillips screwdriver
(not included).
Hardware Used
M6 Flat Washer
M6 x 20 mm Short Screw
EE
3.
Attach the crossbeam assemblies to posts (A)
using bolts (AA) and flat washers (BB). Tighten
with wrench (FF).
Note: The crossbeam assemblies have two
different dimensions. Make sure they are installed
correctly before proceeding. Also make sure the
direction of the crossbeams is correct for so that
the netting tubes can be installed correctly in the
next step.
Hardware Used
M6 x 20 mm Bolt
AA
BB
M6 Flat Washer
M6 Wrench
FF
4.
Attach connectors 1 (G), long mosquito
netting tubes (O) and short mosquito netting
tubes (P) to posts (A) using bolts (AA) and
flat washers (BB). Tighten with wrench (FF).
Hardware Used
M6 x 20 mm Bolt
AA
BB
M6 Flat Washer
M6 Wrench
FF
2
B2
BB
x 8
EE
x 8
N
3
x 32
x 32
x 1
4
x 16
x 16
x 1
