Technical Data - GAUI X5 3D Flybarless Notice D'emploi

11. Technical Data

Fuselage length incl. cabin hood ...................... 1,000 mm
Main rotor diameter ........................................ 1,120 mm
Main rotor blade length ................................... 500 – 530 mm
Height ............................................................ 323 mm
Width ............................................................. 165 mm
Tail rotor diameter .......................................... 230 mm
Tail rotor blade length ..................................... 82 mm
Weight without flight battery ........................... 1,850 g
Recommended electric motor .......................... 1820 W, 910 KV
Recommended speed controller ....................... 100 A
Digital-Servo „GU-501"
Dimensions .................................................... 40.0 x 19.5 x 36.5 mm
Weight ........................................................... 58.5 g
Adjustment time 4.8 / 6 V ............................... 0.16 / 0.13 s
Controlling torque 4.8 / 6 V ............................. 8.0 / 9.5 kg/cm
Retention torque 4.8 / 6 V ............................... 16.0 / 19.0 kg/cm
Gear .............................................................. Partial metal gear
Bearing .......................................................... Double ball-bearing
Digital-Servo „GU-502"
Dimensions .................................................... 40.0 x 19.5 x 36.5 mm
Weight ........................................................... 58.5 g
Adjustment time 4.8 / 6 V ............................... 0.07 / 0.06 s
Controlling torque 4.8 / 6 V ............................. 4.0 / 4.5 kg/cm
Retention torque 4.8 / 6 V ............................... 8.0 / 9.0 kg/cm
Gear .............................................................. Partial metal gear
Bearing .......................................................... Double ball-bearing
