3.
The product is compatible with:
Roof outlet, 160 mm diameter.
•
Façade grille, 160 mm diameter.
•
Recommendations for positioning the new air inlet:
Draw in air a good distance away from contaminated areas (chimneys, ventilation air
•
outlets, boilers, vehicle car parks, etc.) according to the applicable standards.
The new air inlet must be arranged such that it is away from water and cannot become
•
clogged.
The roof outlet must be compatible with the roof type to prevent any water penetration
•
during heavy rain.
The roof outlet or façade grille must be connected to an insulated 160 mm diameter
•
duct.
4.
Individual units
If individual units are installed, each room in use must have a ventilation opening.
OPENING DIMENSIONS BY ROOM TYPE
Room
LIVING ROOM – DINING ROOM, open-plan
LIVING ROOM, separate
DINING ROOM, separate
BEDROOM
OFFICE
Centralised system
If a centralised system is installed, at least one opening must exist in a neutral area (hallway,
staircase, etc.), which is as central as possible within the building to be ventilated.
We recommend a minimum of 2 ventilation openings for areas larger than 110 m
one opening per floor.
The recommended opening diameter is 160 mm.
New air inlet type to be used
Ventilation openings
Diameter in mm
125
80
80
80
80
or at least
²
