SAMES KREMLIN 40C50 AIRLESS Notice Originale page 53


ENCOMBREMENT
Rep. mm
A 400
G 36,5
M Ø 9
D
C
SAMES KREMLIN
Rep. mm Rep.
B 220 C
H 60 I
E
mm Rep. mm
800 D 280
211,5 J Ø 7 x15
A
B
F
- 2 -
Rep. mm Rep.
E 182 F
K Ø 17 L
N° : 578.040.120-FR-1810
mm
35
Ø 9
