-DENCO
Commissioning Record
A-Version
Project Number
End User's Name
FläktGroup Contact
Section A: For completion by commissioning engineer for each unit on site before starting commissioning.
Check installation complies with Operation Manual & Approved Code of Practice-DX Installations
Check & confirm that pipe connections into condensers are correctly orientated i.e. refrigerant liquid line is
nearest to the coil air inlet side. Where condensers are in a tandem configuration, the condensers must be at
the same level, and liquid plus discharge branches must be of equal length
Check & confirm pre-formed discharge line oil traps are fitted (traps manufactured from fittings or bent tube
are not acceptable).
Confirm a signed Pressure Test Certificate has been issued by installer
Check & confirm interconnecting control and power cabling is correct
Check & confirm all electrical connections are secure
Check software version is installed
All instrumentation is covered by a current calibration certificate - including pressure gauges, thermometers,
vacuum gauges, airflow meters.
Heat Load Available During Commissioning Process
Section B: For completion by the Commissioning Engineer for each unit on site
AHU Model No.
AHU Serial No.
AHU Site Reference No.
AHU Location
Electrical Power Supply
Incoming L1 - L2
Incoming L1 - L3
Incoming L2 - L3
Control Voltage
Controls
Display Software Version
Denconet enabled
Network Number of Unit
Interface Card
IP Address
Temperature Set Point
Supply Air Temp Calibration
Supply Air Hum Calibration
Liquid Line Temp Calibration
Air Flow Monitoring Calibration
Discharge Pressure Calibration
Suction Pressure Calibration
Control Type
134
Site Address
COMMISSIONING MUST CEASE IF CONDENSERS OR OIL TRAPS DO NOT MEET REQUIREMENTS
V
V
V
V
Number
Yes / No
Number
Type
Number
°C
°C
% RH
°C
Pa
bar
bar
T or TH
Yes/No
Heat Rejection Model No.
Heat Rejection Serial No.
Heat Rejection Serial No.
Heat Rejection Location
Incoming L1 - N
Incoming L2 - N
Incoming L3 - N
Controller Software Version
Denconet Configuration
Network Number of Display
Subnet Mask
BMS Address
Humidity Set Point
Return Air Temp Calibration
Return Air Hum Calibration
Ambient Temp Calibration
Discharge Temp Calibration
Suction Temp Calibration
Control Type
Page 2 of 4
Based on DQA800
FläktGroup DC-2013-0101-FR_R6-09/2022 • Sous réserve de modifications
Multi-DENCO
Initial Box =
Initial Box =
Initial Box =
Initial Box =
Initial Box =
Initial Box =
Initial Box =
Initial Box =
Available kW
V
V
V
Number
Type
Number
Number
Number
% RH
°C
% RH
°C
°C
°C
P or PI
