Charge The Battery; Mower Blade Stop Time; Change The Engine Oil - Snapper SPX RIDING MOWER Manuel D'utilisation

10

Charge the Battery

WARNING
Keep open flames and sparks away from the battery.
Gasses from the battery are very explosive.
A dead battery or one too weak to start the engine can
be the result of a defect in the charging system or other
electrical component. If there are doubts about the cause of
the problem, see an Authorized Service Dealer. To replace
the battery, see Clean the Battery and Cables.

Mower Blade Stop Time

WARNING
If the mower blade does not STOP in 5 seconds or less, the
clutch must be adjusted. DO NOT operate the machine
until the adjustment has been corrected by a Briggs &
Stratton Authorized Service Dealer.
After the Power Take-Off (PTO) switch turns OFF, the mower
blades and mower drive belt must STOP in 5 seconds or
less. If the mower drive belt does not STOP in 5 seconds,
contact Briggs & Stratton Authorized Service Dealer for
repairs.

Change the Engine Oil

1. Put the rider on a level surface (A, Figure 11).
2. Stop the engine and remove starter insert or key (B).
3. Clean the oil fill and filter areas.
4. Remove the dipstick (C).
16
11
5. Disconnect the oil drain hose (A, Figure 12)
6. Carefully remove the cap (B), and lower the hose into an
approved container (C).
