Reverse Mowing Option (Rmo) - Snapper SPX RIDING MOWER Manuel D'utilisation

6. Use the Height-of-Cut Electric Switch (R) to set the
cutting height to the desired level. See Adjusting the
Mower Cutting Height.
7. Disengage the parking brake control, then begin to mow.
8. Disengage the PTO.
9. STOP the engine. See Stop the Engine.
WARNING
The engine will STOP if the reverse ground speed pedal is
depressed while the PTO is ON and the RMO has not been
activated. Always disengage the PTO OFF before tractor
operation. Sudden loss of drive could create a hazard.
CentreCut™ Mower Decks
Some models feature a CentreCut™ mower deck that can be
configured for side discharge or rear eject operation.
To convert between available mower deck configurations, see
your dealer.
WARNING
A complete Configuration Kit must be fully installed on the
CentreCut™ mower deck before operation. Do not operate
the unit without a complete Configuration Kit fully installed.
See your dealer.
Adjust the Mower Cutting Height
The mower lift lever (Q, Figure 3) lowers the deck to cutting
position or raises the deck to the transport position.
1. Lower the deck:
A. Slightly pull back on the mower lift lever.
B. Push the mower lift lever to the left.
C. Push DOWN on the mower lift lever.
2. Raise the deck:
A. Pull UP on the mower lift lever.
B. Lock in the notch to the right.
Note: DO NOT cut when the deck is raised to transport
position.
Note: The height-of-cut switch (R, Figure 3) controls the
mower cutting height. It adjusts the cutting height between 1.5
- 3.5 in. (2.5 - 8.89 cm). See Specifications.
14

Reverse Mowing Option (RMO)

DANGER
Mowing in reverse can be hazardous to bystanders.
Tragic accidents can occur if the operator is not alert to
the presence of children. Children are often attracted to
the machine and the mowing activity. Never assume that
children will remain where you last saw them.
• Keep children out of the operating area and under the
watchful care of a responsible adult.
• Do not carry passengers, especially children, even
with the blade(s) shut off. Children can fall off and be
seriously injured or interfere with the safe machine
operation. Children who have been given rides in
the past can suddenly appear in the mowing area for
another ride and be run over or backed over by the
machine.
• Do not mow in reverse unless absolutely necessary.
Always look down and behind before and while
backing.
• If the machine mows in reverse without Reverse
Mowing Option activated, see an authorized dealer
immediately.
1. Engage the Power Take-Off (PTO) (E, Figure 3).
2. Set the Reverse Mowing Option (RMO) key (B) to the ON
position.
3. The L.E.D. light comes on.
4. The operator mows in reverse.
Note: Remove the key to restrict access to the RMO.
