General Description - Astralpool MULTI-PARAMETRIC INSTRUMENT Manuel D'installation

•
Protection
−
IP65
•
The device must be utilized within the specified environmental temperature, humidity and pressure
limits. The instrument is designed to operate under the following environmental conditions:
−
Temperature of the working environment
−
Storage and transport temperature
−
Relative humidity
ATTENTION: The device must be perfectly inserted into the system.
The system must be maintained operational in full compliance with the foreseen safety regulations.
The parameters set on the analyser's control unit must comply with the current regulations.
The control unit's malfunction signals must be located in an area that is constantly supervised by
the system's maintenance personnel or operators.
Failure to respect even just one of these conditions could cause the control unit's "logic" to operate
in a potentially dangerous manner for the users of the service.
In order to avoid any potentially dangerous situations, therefore, the system's service and/or
maintenance personnel are advised to work with the utmost care and to signal any alterations in
the safety parameters in a timely fashion.
As the above issues cannot be monitored by the product in question, the manufacturer shall bear
no responsibility for any property damage or personal injury which may result from such
malfunctions.
2.

GENERAL DESCRIPTION

The analyser described in this manual is comprised of the instrument itself as well as the Technical Manual.
The device may be installed upon the electrical panel or else wall-mounted at a maximum distance of 15 metres
from the probe.
It is powered by the mains electrical system (100-240Vac-50/60Hz), with 15W consumption, through a switching
Power Supply.
This device has been designed for the ON-LINE analysis of chemical characteristics in the following applications:
•
Biological oxidation systems
•
Industrial wastewater drainage and treatment
•
Fish farming
•
Primary or drinking water systems
0°C to +40°C
-25°C to +65°C
00% to 95% - (without condensation)
0000137242 Rev.3.1 3
