4.3 SETTINGS MENU (menu navigation index = 3)
Select the menu item to be set and press ENTER to confirm.
3------------------SETTINGS-----------------
3A pH
3B CHLORINE
3C REDOX
Using the following structure, the settings menu is divided into levels in order to allow for the easy
identification of the sub-menus
•
3 Settings
o
3A pH
3A1 Relays
3A2 Frequency Output
3A3 Current Output
3A4 Alarms
o
3B Chlorine
3B1 Relays
3B2 Frequency Output
3B3 Current Output
3B4 Alarms
3B5 Reference temperature for chlorine measurement.
3B6 Compensation of chlorine measurement based on conductivity present in
water.
o
3C Redox
3C1 Relays
3C2 Frequency Output
3C3 Current Output
3C4 Alarms
o
3D Temperature
3D1 Relays
3D2 Frequency Output
3D3 Current Output
3D4 Alarms
Detailed instructions for setting the parameters are provided below.
↓
•
ON/OFF Settings
•
Timed Settings
•
Proportional Settings
•
ON/OFF Settings
•
Timed Settings
•
Proportional Settings
•
ON/OFF Settings
•
Timed Settings
•
Proportional Settings
•
ON/OFF Settings
•
Timed Settings
•
Proportional Settings
