4.3.3 REDOX MEASUREMENT SETTINGS MENU (menu index 3C)
"This menu is available on the pH–Chlorine and pH–Chlorine–Redox System version"
Use the UP and DOWN keys to scroll through the various menus and submenus and to modify the data
(increase/decrease).
Use the ENTER key to access the data insertion submenus and to confirm any modifications.
3C REDOX DOSING
3C1 RELAY
3C2 FMW
3C3 OUTmA
The various items contained within the Redox measurement sub-menus are described below:
•
Menu index "3C1" REDOX RELAY
3C1 RELAY REDOX
>ON/OFF
TIMED
PWM
The various items contained within the pH relay's sub-menus are described below, with their various modes,
ranges and settings:
Item
On/Off:
SetPoint:
Dose Type:
Hysteresis:
Hysteresis Time:
Start Delay:
End Delay:
Timed
SetPoint:
Dose Type:
Hysteresis:
Hysteresis Time:
Start Delay:
End Delay:
On Time:
Off Time:
Proportional (PWM)
SetPoint:
Dose Type:
Hysteresis:
Hysteresis Time:
Start Delay:
End Delay:
Period:
Proportional Band:
ON/OFF
↓
Default Value
700 mV
Low
Off
Off
Off
Off
700 mV
Low
Off
Off
Off
Off
1
1
700 mV
Low
Off
Off
Off
Off
20 seconds
300 mV
0000137242
3C REDOX DOSING
3C2 FWM
3C3 OUTmA
3C4 ALARMS
The Redox relay's settings can be varied as follows:
•
ON/OFF (SetPoint threshold dosing)
•
TIMED (Timed dosing)
•
PWM (Proportional dosing)
±2000 mV
High / Low
10-600 mV
1-900 Seconds
3-900 Seconds
3-900 Seconds
±2000 mV
High / Low
10-600 mV
1-900 Seconds
3-900 Seconds
3-900 Seconds
1-1800 Sec
1-1800 Sec
±2000 mV
High / Low
10-600 mV
1-900 Seconds
3-900 Seconds
3-900 Seconds
20-1800
20-600 mV
Rev.3.1
↑
Range
