Astralpool MULTI-PARAMETRIC INSTRUMENT Manuel D'installation page 12

MAN
pH CAL.
pH CAL.
7.01pH 25.0°C
pH CAL.
7.00pH 25.0°C
Wait 60"
pH CAL.
4.01pH 25.0°C
Wait 60"
At the end of each calibration point, the instrument will display the quality of the electrode as a percentage.
3.3.2 ORP (REDOX) PROBE CALIBRATION
Connect the ORP probe to the instrument as indicated in the electrical connections.
Select the ORP probe from the Calibration menu.
Select whether to perform the calibration in Automatic (AUTO) or Manual (MAN) mode.
AUTO
ORP CAL.
ORP CAL.
+475mV
ORP CAL.
+475mV
Wait 60"
At the end of each calibration point, the instrument will display the quality of the electrode as a percentage.
In Automatic (MAN) mode:
Type: Man
Type: Man
Type: Man
Type: Man
In Automatic (AUTO) mode:
Type: Auto
Type: Auto
Type: Auto
0000137242 Rev.3.1
•
Immerse the probe in the first solution, insert
the solution's pH value and press Enter
•
Wait 60 seconds. When finished, the
instrument will display the probe's quality as
a percentage value.
•
Immerse the probe in the second solution
and insert the solution's pH value..
•
Wait 60 seconds. When finished, the
instrument will display the probe's quality as
a percentage value.
•
Once the operation has concluded, a
message will appear indicating that the
calibration has been carried out successfully.
•
Immerse the probe in the +475mV solution
and press Enter
•
Wait 60 seconds. When finished, the
instrument will display the probe's quality as
a percentage value.
•
Once the operation has concluded, a
message will appear indicating that the
calibration has been carried out successfully.
10
