XA01736T

Connection data

Type
TMT7x
Order option:
TMT7x-xxx1xxxx
(head transmitter)
TMT7x-xxx2xxxx
TMT7x-xxx3xxxx
(DIN rail transmitter)
Category
Type of protection (ATEX)
II1G
Ex ia IIC T6...T4 Ga
II2G
Ex ia IIC T6...T4 Gb
II2(1)G
Ex ia [ia Ga] IIC T6... T4 Gb
II2(1)G
Ex ib [ia Ga] IIC T6... T4 Gb
Type of protection (IEC)
Ex ia IIC T6...T4 Ga
Ex ia IIC T6...T4 Gb
Ex ia [ia Ga] IIC T6... T4 Gb
Ex ib [ia Ga] IIC T6... T4 Gb
20
Electrical data
Power supply
(+ and - terminals)
Sensor circuit
(terminals 3 to 6)
Max. connection data
Ex ia IIC
Ex ia IIB
Ex ia IIA
Ui ≤ 30 V
DC
Ii ≤ 100 mA
Pi = 800 mW (head transmitter)
Pi = 700 mW (DIN rail transmitter)
Ci = negligible
Li = negligible
Uo ≤ 4.3 V
DC
Io ≤ 4.8 mA
Po ≤ 5.2 mW
Lo = 50 mH
Lo = 100 mH
Lo = 100 mH
Type
without display
with display
with field housing
with DIN rail housing
Type
without display
with display
with field housing
with DIN rail housing
iTEMP TMT71, TMT72
Co = 3 µF
Co = 18 µF
Co = 48 µF
