Functions of the remote control

Impact of the control lever positions on the model
(Directions seen in flight direction)
Ascent
(Pitch)
Descent
(Pitch)
Rotation right
(Tail)
Rotation lift
(Tail)
Nick: Forwards flight
(Lower nose)
Nick: Backwards
flight
(Raise nose)
Roll left
Roll right
If the model reacts precisely the opposite to one or more control functions, you can press the
corresponding servo reverse switches on the front of the transmitter to change the reaction direction.
Vers ion 09/07
Left control lever
forwards
Left control lever
backwards
Left control lever
to the right
Left control lever
to the left
CARSON Apache 4CH 507000
Right control lever
forwards
Right control lever
backwards
Right control lever
to the left
Right control lever
to the right
13
