RCA RCU807 Mode D'emploi page 17

RCU807US_IB_REVB 9/26/03
MENU KEY
The MENU key brings up the Main Menu. If you are already in the menu system,
press and release the SELECT/OK, ENTER, or MENU keys to select a highlighted choice.
Use the NAVIGATION keys (UP, DOWN, LEFT, and RIGHT ARROW keys) to move
through the menu selections.
With some brands, the CH+, CH-, VOL+ and VOL- keys navigate through
NOTE:
the highlighted choices.
MUTE KEY
The MUTE key mutes the volume on your component with volume control.
NAVIGATION KEYS & SELECT/OK KEY
Use the NAVIGATION keys (UP, DOWN, LEFT and RIGHT ARROW keys) to move
through on-screen menu and guides. The NAVIGATION keys may also be used to move
through the highlighted choices. The SELECT/OK key chooses the highlighted choice.
With some manufactured models, the MENU or ENTER key is used to select
NOTE:
the highlighted choices.
PIP & SWAP KEYS
The Picture-in-Picture (PIP) and SWAP keys operate your TV's Picture-in-Picture,
if equipped with this feature.
PUNCH-THROUGH
A Punch-through command has the ability to punch through from one component to another
(e.g., pressing the TV VOL+/VOL- keys can work while the remote is in the VCR Mode).
REVERSE, PLAY, FORWARD, RECORD, STOP, PAUSE KEYS
These keys operate the same as your existing remotes.
SETUP (S) KEY
The SETUP (S) key is used to walk you through the steps in setting up the remote. Setup is used
for Code List Entry, Code Search, Code Identification and other functions. During a Setup function,
if no key is pressed for 30 seconds, the remote automatically exits from the Setup routine.
SLEEP (ZZZ) KEY
The SLEEP (ZZZ) key allows you to turn your TV off automatically, if equipped
with this feature.
SMARTMACRO
When programmed, the SmartMacro function causes a series of events to occur in sequential order.
Once programmed, pressing the MACRO (M) key and 1, 2, or 3 digit keys activates one of your
programmed Macros. An example of a Macro sequence could be "Turn on the TV; then turn on
the satellite receiver; then set it to channel 57." You can program and store three SmartMacros,
each consisting of up to six commands.
TIMER
This feature allows an event to happen at a later time on the current day, such as "Turn the TV
on at 7:00 PM." The Timer Mode allows you to set up to four individual commands and must be
reprogrammed after each event occurs.
TV•VCR KEY
The TV•VCR key operates the same as the TV/VCR or antenna keys on your original remotes.
VOLUME AND CHANNEL KEYS
The VOLUME and CHANNEL keys (VOL+/VOL-, CH+ and CH- keys) increase
and decrease the volume level and channel numbers.
With some brands, these keys also navigate through the highlighted choices
NOTE:
in the menu options.
10:18 Page 17
17
