Clear All Stored Learned Commands
Under a Component Mode
It is recommended that you clear all Learned commands under a component mode before
attempting any Learning under that mode. If you want to clear all of the Learned commands
under one component mode (e.g., TV, VCR, DVD, etc.), follow these steps:
Upon deletion of Learned commands, all previously Learned
Note:
keys under that component mode return to their preset code functions.
1. Press and hold the SETUP (S) key for 2-3 seconds
until the status display shows the Setup Mode? Screen.
2. Release the SETUP (S) key.
3. Press and release the SETUP (S) key repeatedly
until the Clear Mode? Screen appears.
4. Press and release the desired component key for the
Learned commands you want the RCU807 to clear
(TV, VCR, SAT•CBL, AUX1, etc.). The chosen component
will appear in the display.
5. Press and release the ENTER key.
The display shows the Clearing Wait Screen.
If, at this point, you wish to cancel this process,
Note:
press and release the CLEAR key.
6. The LCD display shows the Success Screen,
then returns to the normal time display.
7. All Learned commands that were previously stored
under that component mode are now cleared. If you
wish to clear all Learned commands under another
component mode, repeat steps 1-6.
SmartMacro Key Operations
™
Your RCU807's SmartMacro feature allows you to execute a sequence of commands with only
two keypresses. A SmartMacro learns any sequence of original remote commands. A total of six
Learned commands can be programmed under each of the three MACRO 1, 2, and 3 digit keys.
If you program all six keystrokes into a SmartMacro, the Macro is automatically stored after the
sixth Learned command is completed. The commands you want a SmartMacro to execute must be
programmed in correct sequential order. Any sequence of commands that you regularly perform
can be programmed as a SmartMacro and reduced to two keypresses, MACRO (M) followed by
the 1, 2, or 3 digit key. You cannot program a Macro within a Macro.

Program a SmartMacro

Example of Programming a Macro
1. Turn on the TV.
2. Turn on the satellite receiver and set it to channel 57.
3. Turn on the VCR.
4. Now you're ready to record your favorite satellite program with two simple keypresses.
To program a SmartMacro, follow these steps:
1. Gather all your original remotes that contain functions
you would like to add to a SmartMacro.
2. Place the first original remote in the Learning position.
Point the top of the original remote at the base of the RCU807
so the IR LED on the original remote is in line with the
RCU807 Learn sensor, located at the bottom of the remote.
The remotes should be positioned 2-3 inches apart.
3. Press and hold the RCU807 SETUP (S) key for 2-3 seconds
until the LCD display shows the Setup Mode? Screen.
