UNIC
REP REF
1 CN-648 COMPTEUR VOLUMETRIQUE
2 DV-44 VIS TH M4X10 ACIER
3 CN-618 JOINT CUIVRE 11,4 x 6,2 x 1
4 23751 AXE DE BANJO 1/8
5 28104 JOINT TORIQUE 2X9,5 FKM 80SH
6 20403 RACCORD NOURRICE 3/8M-1/4M
7 CH-16 JOINT CUIVRE RECUIT 3/8
8 25400 FILTRE PROTECTION E.V 1/8
9 DV6014 TUBE CUIVRE MANOMETRE HP
10 DO-191 SOUPAPE H.P. COMPLETE
11 CN-631 ELECTROVANNE 2V REGL.220V50HZ
11 CN-631B ELECTROVANNE REG 220-60/208-50
11 CN-631C ELECTROVANNE 2V REGL 110V60HZ
11 CN-245B BOBINE ELECTROV. 2V 220V50HZ
11 CN-245C BOBINE EV 2V 220-60/208-50
11 MI-78 BOBINE EV.110V 60HZ/100V 50HZ
12 MI-18 RACCORD MM 1/4 - 1/8 G.
13 DV-203 JOINT PLAT CUIVRE 1/4 D:2mm
All manuals and user guides at all-guides.com
PLANCHE/PLATE : 450
DESIGNATION
WHOLE W.DOSING DEVICE F UNIT
SCREW M4x10
GASKET - 11.4 x 6.2 X 1
BANJO SCREW
GASKET 2X9,5
FITTING 3/8M-1/4M
WASHER - COPPER - 3/8
FILTER FOR EV 1/8
PIPE HP MANOMETER
COMPLET H.P. VALVE
ELECTROVANNE 2W ADJ 220-50Hz
ELECTROVALVE ADJ.220-60/208-50
WHOLE FLOW ADJ. EV 110V60HZ
ELECTROVALVE COIL 220V-50HZ
EV COIL 2W 220-60/208-50
SOLENOID COIL - 1 WAY 110V60H
FITTING - 1/8 x 1/4
WASHER 1/4 D:2
16/04/2004
