4. STARTING-UP
4.1 FILLING THE BOILERS
-
Turn on the shutoff valve.
-
Plug in the machine.
-
Set the charge switch to Position 1. Do not set the charge switch to
Position 2 until the boiler has been filled.
4.1a STEAM BOILER
- As soon as the machine is turned on, the filling takes place automatically.A safety is programmed, if the filling
does not occur before 3 minutes. In this special case, the electrovalve and the pump are cut off. The indicator light
blinks when steam and hot water outlets are not activated.If after 3 minutes the indicator light is still blinking :
- Check the hydraulic connection of the machine.
- Switch off and switch on the machine by setting the charge switch to position 0 then to position 1.
The filling starts again and lasts 3 minutes.
4.1b INTERNAL BOILERS
- With the filter holder in place, press the continuous/stop key of each unit
As soon as the water flows correctly from the spout (with no air), press the same key again to stop the
water.
4.2 HEATING
-
When the boilers have been filled, set the charge switch to Position 2.
-
When the operating temperature of the machine is reached, the pressure-gauge must indicate a pressure of
0.9 to 1 bar (red scale).
It is better to keep the machine switched on permanently and the filter-holders inserted in machine
even when you are not making coffees.
.
5. CHECKS AND ADJUSTMENTS
.To get to the various adjustments, the cup rack, the rear panel or the sides must be removed.
Proceed as follows:
.CUP RACK:
Remove the grids, than unscrew the
four upper screws and the two side
screws. Than remove the cup rack.
.REAR PANEL(S):
Unscrew the two screws located inside
the machine at its back; than make the
panel(s) glide laterally.
.SIDES:
On each side, unscrew two screws of the
cup rack and pull up the side.
All manuals and user guides at all-guides.com
- 3 -
ON/OFF SWITCH
\\
.
