UNIC
REP
REF
1
DV1049
EMBOUT DE DECOMPRESSION
2
DV6039
TUBE CUIVRE DE DECOMPRESSION
3
24455
ECROU 1/8
4
PI-45X
ELECTROV. V 1 SANS BOBINE
5
MI-80
VIS TCHC M4x12 INOX
7
23107
GICLEUR DIAM:0,7
9
PH-54
JOINT TORIQUE 2,62X13,95 EPDM
8
CF-326
FILTRE INOX D.int=12 H=17,5
10
23100
PORTE GICLEUR
12
PC-45
RONDELLE GROVER DE 10
13
CH-64
ECROU ACIER ZN Hu 10
11
CH-63
GOUJON ACIER NICKELE M10
6
ID-18
CORPS DE GROUPE INJECTION
14
083501
JOINT TORIQUE 3,53 X 29,75 FKM
15
DV-97
PORTE FILTRE INTERFACE CHROME
16
50401
VIS TCHC TETE BASSE M8X16 INOX
17
083500
DOUCHETTE INOX
18
CN-128
VIS INOX TF M4 X 8
19
083504
JOINT TORIQUE 5,34 X 43,82 FKM
20
6639
FILTRE INOX D 33mm
20
6640
FILTRE ILLYCAFFE D 35mm
20
6647
FILTRE ILLYCAFFE D 31mm /1
21
6786
PORTE FILTRE ILLY
22
CH-17
JOINT CUIVRE RECUIT 1/2
23
DV-89
TUBE ALIM. POUR PHOENIX-R
24
ID-23
RACCORD ALIM.1/2M-M
25
DV-88
BOUCHON EN TEFLON
26
PE-28
JOINT TORIQUE 3,53X36,09 FKM
All manuals and user guides at all-guides.com
PLANCHE/PLATE : 245
DESIGNATION
DECOMPRESSION TIP
DECOMPRESSION PIPE
NUT 1/8
ELECTOVALVE 3W WITHOUT COIL
SCREW M4 X 12
GICLUER DIAM. 0.7
GASKET - 13.95 x 2.62
FILTER D:12 H:17,5
FILTER SCREEN BODY
WASHER
NUT M10
SCREW M10 -STUD
GROUP BODY - EROGATION
GASKET 3,53 X 29,75 FKMV
INTERFACE FILTER HOLDER
SCREW M8 X 16
SPRAY
SCREW M4 X 9 CSH
GASKET 5,34 X 43,82 FKMV
NOTCH FILTER 33mm STAND. CUP
NOTCH FILTER 35mm # 3 LARG. CUP
NOTCH FILTER 31mm SHORT CUP
FILTER SCREEN BODY
WASHER - COPPER - 1/2
MIXING TUBE-TEFLON-GROUP
FITTING 1/2-1/2
PLUG
GASKET - 36.09 x 3.53
27/04/2004
