System Features

The major hardware and software features of your system include:
1U/1S rack-mountable chassis with support for static rails and sliding rails.
NOTE:
Use the System Setup program to view processor information.
See "Using the System Setup Program" in your Hardware Owner's Manual.
One of the following processors:
®
Intel
Celeron
Intel Pentium
Intel Core 2 Duo™
Dual-Core Intel Xeon
Quad-Core Intel Xeon Processor 3200 Series.
A minimum of 512 MB of 667-MHz or 800-MHz DDR2 SDRAM memory,
upgradable to a maximum of 8 GB by installing combinations of 512-MB,
1-GB, or 2-GB unbuffered ECC memory modules in four memory module
sockets on the system board.
One of the following riser card options:
One full-height, half-length, x8 lane PCIe expansion slot and one full-
height, half-length PCIe expansion slot with a x8 connector but with
a x4 lane capability.
One full-height, half-length, 133MHz/64 bit PCI-X expansion slot and
one full-height, half-length, x8 lane PCIe expansion slot, which
includes a connector for an optional remote access controller (RAC)
card.
One 3.5-inch CD, DVD, or combination CD-RW/DVD in a peripheral
drive bay.
Support for the following internal hard-drive configurations:
Up to two internal, 1-inch high, SATA hard drives with the integrated
drive controllers.
Up to two internal, 1-inch high optional Serial-Attached SCSI (SAS)
hard drives with an optional SAS controller card.
Optional remote access controller for remote systems management.
This option requires a riser card with support for PCI-X and PCIe RAC
connectors.
Optional USB flash drive emulates a diskette drive or hard drive.
One 345-W power supply.
®
®
Dual-Core™
®
Processor 3000 Series
Getting Started Guide
3
