Measuring

1. Launch the PlateQuality Flexo software. If the vipFLEX
preview will be started automatically, otherwise click on the Preview
2. Select the substrate type (film, plate, print) on the vipFLEX
selected will be indicated by an LED. Details on the substrate type can be found in the help of the PlateQuality
Flexo software.
3. In the software program, select the substrate type being used.
4. Place the measurement sample onto the measurement table above the measuring aperture.
5. Press the measuring arm onto the sample (the measuring arm will then press down automatically). Then release
the measuring arm to ensure that an even pressure is being exerted on the measuring sample during the
measurement.
6. Click
More details on conducting measurements can be found in the help of the PlateQuality Flexo software.
8
All manuals and user guides at all-guides.com
to conduct an automatic measurement.
2
measuring device is detected correctly, the video
button.
2
measuring device. The substrate type currently
