1. Low oil level—add oil
B. Install the dipstick securely.

Replacing the Spark Plug

Service Interval: Every 100 hours—Replace the spark plug.
WARNING
Replacing the spark plug while the engine is hot
can result in burns.
Wait until the engine is cool to replace the spark
plug.
Use a Toro spark plug or equivalent (Champion® RN9YC or
NGK BPR6ES).
1. Remove the boot
(Figure
1. Spark-plug boot
2. Clean around the base of the spark plug.
3. Remove and discard the old spark plug.
Figure 18
2. Correct oil level
19).
Figure 19
Note: You will need a ratchet wrench extension to
remove the spark plug.
4. Set the gap between the electrodes on a new spark plug
at 0.76 mm (0.030 inch) as shown in
1. 0.76 mm (0.030 inch)

Adjusting the Auger Cable

Service Interval: After the first 2 hours
Yearly
If the drive belt slips or squeals under heavy load, adjust the
auger cable.
1. Loosen the nut on the lower cable clamp, but do not
remove it
(Figure
1. Nut
2. Cable
2. Pull the cable up to remove some slack
Important: Do not remove all the slack from
the cable. Removing all the slack from the cable
prevents the auger from stopping properly.
3. Hold the cable in place and tighten the nut
14
Figure
Figure 20
21).
Figure 21
3. Connector
4. Spring
(Figure
20.
21).
(Figure
21).
