Nobles READY SPACE STRIVE COMPACT Manuel Opérateur page 61

Ref. Part No. Serial Number
1 1045325 (10000000--20000000
2 1027144 (10000000--20000000
3 01684 (10000000--20000000
4 1054903 (10000000--20000000
5 9007963 (10000000--20000000

6 1019349 (10000000--20000000
Y
7 1030682 (10000000--20000000
Y
8 1030680 (10000000--20000000
Y
9 01543 (10000000--20000000
Y
10 1035298 (10000000--20000000

11 1045465 (10000000--20000000
Y
12 09162 (10000000--20000000
13 1030623 (10000000--20000000
14 01684 (10000000--20000000
15 07515 (10000000--20000000
16 34323 (10000000--20000000
17 1037928 (10000000--20000000
18 1019349 (10000000--20000000
19 140946 (10000000--20000000
20 140534 (10000000--20000000
21 1028953 (10000000--20000000
22 386868 (10000000--20000000
23 07515 (10000000--20000000
24 1042443 (10000000--20000000
25 140060 (10000000--20000000
26 08712 (10000000--20000000
27 15678 (10000000--20000000
28 9004280 (10000000--20000000
29 9004282 (10000000--20000000
30 130288 (10000000--20000000
 ASSEMBLY
INCLUDED IN ASSEMBLY
Y
Nobles StriveR Compact (07- -2010)
All manuals and user guides at all-guides.com
SCRUB HEAD GROUP
Description
) Screw, Hex, M6 X 1.00 X 45, Ss
) Washer, Lock, Int, M6, Ss
) Washer, Flat, 0.27b 0.69d .05, Ss
) Housing, Brush, Dbl, 40cm
) Door Kit, Brush, W/ Hdwr
) Screw, Trs, M6 X 1.00 X 16, Ss, Sems
) Shaft, Idler Plug
) Hub, Idler, Brush
) Ring, Retaining, Ext, 0.39d, Basic
) Motor, .25hp, 115vdc, 2.1a, 1550 Rpm
) Brush, Carbon (Pk=2) Ref Part 1035298
) Screw, Set, Soc, M6 X 1.00 X 8, Nl
) Sheave, 07grv, 16.03pd [Ph]
) Washer, Flat, 0.27b 0.69d .05, Ss
) Washer, Lock, Int, 0.25, Ss
) Screw, Hex, .25--20 X 0.75, Nl
) Cover, Belt, Spg (Dual Roller)
) Screw, Trs, M6 X 1.00 X 16, Ss, Sems
) Screw, Rnd, Sltd, 06--32 X 1.00, Nyl
) Nut, Hex, #06--32, Nyl
) Roller Assy, Readyspace
) Screw, Hex, M8 X 1.25 X 12, Ss
) Washer, Lock, Int, 0.25, Ss
) Support, Kickstand, Blk, Nyl
) Washer .505x.750x.045 Wave
) Nut, Hex, Lock, M6 X 1.00, Nl, Ss
) Screw, Hex, M6 X 1.00 X 16, Ss
) Bracket, Motor Mount W/ Bearing/Seal Kit
) Belt Kit, W/ Installation Tool [Qty 2]
) Rectifier, Bridge, Rnd, 12a 1000volt, Ce
STANDARD PARTS
Qty.
8
8
8
1
1
2
2
2
2
2
4
4
2
4
4
4
1
2
1
1
2
1
1
1
1
3
3
1
1
1
19
