Ref. Part No. Serial Number
1 1037759 (10000000--20000000
2 1035358 (10000000--20000000
3 24555 (10000000--20000000
4 1016399 (10000000--20000000
5 140027 (10000000--20000000
6 1034346 (10000000--20000000
7 1036063 (10000000--20000000
8 140340 (10000000--20000000
9 1042715 (10000000--20000000
10 1032556 (10000000--20000000
11 140011 (10000000--20000000
12 1051274 (10000000--20000000
13 1042277 (10000000--20000000
14 1044370 (10000000--20000000
15 9005924 (10000000--20000000

16 1036090 (10000000--20000000
Y
17 1052876 (10000000--20000000
Y
18 602849 (10000000--20000000
Y
19 1035866 (10000000--20000000
20 1037756 (10000000--20000000
21 140308 (10000000--20000000
22 1054345 (10451589--20000000
 ASSEMBLY
INCLUDED IN ASSEMBLY
Y
Nobles StriveR Compact (04- -2012)
All manuals and user guides at all-guides.com
TANK COVER GROUP
Description
) Cover , Tanks, Upper, Nobles [Trex]
) Pin, Grvd, 0.375d, 1.25l
) Ring, Retaining, Ext, 0.38d, [E--Ring]
) Screw, Hex, M8 X 1.25 X 30, Nl, Ss
) Washer, Flat, 0.35b 0.75d .04, Ss
) Bracket, Pivot, Cover, Mtg
) Hose, Soltn, .25 Id, .453 Od, 56.0 L
) Screw, Pan, Phl, 10--24 X 0.62, Ss[Typ25]
) Fitting, Brs, Str, Bm04/Pm02
) Filter, Soltn Tube, 80 Mesh
) Washer, Flat, 0.21b 0.45d .03, Ss
) Gasket, Shield, Float
) Shield, Float
) Ball, Float, W/O Cage
) Cover, Tank, Inner W/ Seals, Kit
) Seal, Vacuum [Trex]
) Gasket, Tank
) Strainrelief, Cord, Ele, Pm08, Blk Nyl
) Hose, Recvy, Formed [Trex]
) Hose, Vacuum, 1.5od, 18.0l [Wire--Reinf]
) Clamp, Hose, Wormdrive, 1.31--2.25d, .50w
) Clip, Retaining, Seal
STANDARD PARTS
Qty.
1
2
2
4
4
1
1
13
1
1
2
1
1
1
1
2
2
1
1
1
4
2
13
