3. Ceiling Fan Assembly
3.15
Place the Ceiling Cover over the Downrod .
Be sure both the Ceiling Cover and the Coupler Cover
are oriented correctly (Figure 13) .
3.16
NOTE: Only use the Hanger Ball supplied with this
Ceiling Fan.
Route the Three 80" Motor Wires through the Hanger
Ball .
Reinstall the Hanger Ball (Figure 14) on the Downrod
as follows:
Position the Hanger Ball Pin through the two holes in
the Downrod and align the Ball so the Pin is captured in
the Groove in the top of the Hanger Ball .
Pull the Hanger Ball up tight against the Pin and
securely tighten the Set Screw in the Hanger Ball .
NOTE: A loose Set Screw could create fan wobble.
(Continued)
DOWNROD
CEILING
COVER
Figure 13
PIN
HANGER
BALL
DOWNROD
Figure 14
Please contact 1-800-777-4440 for further assistance
11
CEILING
COVER
luminancebrands.com
ETL Model No.: CF880L
