AERASGARD RCO2 - A NT
Maintenance-free AERASGARD
elegant plastic housing, for determining the CO2 content of room air (0...3000 ppm). The measuring transducer converts the measurand to a
standard signal, which is directly presented visually by five coloured LEDs (traffic light indicator). Available in device versions RCO2-A NT for direct
wall mounting, RCO2-A UPNT for recessed installation on flush-mounting socket and RCO2-A NT ST with metal stand for flexible positioning.
The room sensor is designed for use in class, seminar and meeting rooms, offices, hotels, homes, shops etc. and provides a simple and fast way of
assessing the room climate. This enables an energy saving and on-demand room ventilation, thus reducing the overall operating costs and enhancing
the well-being of occupants. One sensor for every 30 m² of space is recommended.
The CO2 content is measured with an optical NDIR sensor (non-dispersive infra-red technology).
TECHNICAL DATA
Power supply:
Electrical connection:
Sensor:
Measurement range:
Measuring accuracy:
Temperature dependence:
Pressure dependence:
Long-term stability:
Gas exchange:
Ambient temperature:
Warm-up time:
Measuring interval:
Housing:
Dimensions:
Installation:
Protection class:
IP rating:
Standards:
Equipment:
®
AERASGARD
RCO2-A NT
CO2 sensor for schools with traffic light display and power supply unit
Type ⁄ WG02 Measuring ranges
CO2
RCO2 -A NT
R C O 2 - A N T 0...3000 ppm
R C O 2 - A N T S T 0...3000 ppm
R C O 2 - A U P N T 0...3000 ppm
Note: This unit must not be used as safety-relevant device!
CO2 sensor for schools (RCO2-A NT ) with traffic light display, incl. power supply unit, self-calibrating, in an
®
RCO2-A UPNT : 24 V AC ⁄ DC (± 10 %)
RCO2-A NT, RCO2-A NT ST : 230 V AC (50 -60 Hz)
power supply unit 230 V ⁄ 50 -60 Hz (included in the scope of delivery)
optical NDIR sensor (non-dispersive infrared technology),
with manual calibration (via zero button),
with automatic calibration (permanently active)
0...3000 ppm
typically ± 30 ppm ± 3% of measured value
± 5 ppm ⁄ °C or ± 0.5% of measured value ⁄ °C
(whichever is greater)
± 0.13% ⁄ mm Hg
< 2% in 15 years
by diffusion
0...+ 50 °C
approx. 1 hour
< 3 seconds
plastic, material ABS, colour pure white (similar to RAL 9010)
85 x 85 x 27 mm (Baldur 1)
RCO2-A NT, RCO2-A UPNT :
directly on wall or on flush-mounting socket, Ø 55 mm, 4-hole base part,
for installation on vertically or horizontally installed flush-mounting socket
with cable entry from behind, with breaking points for on-wall installation
and cable entry from above or below
RCO2-A NT ST :
immediately usable free-standing device with wall power supply (plug-and-play)
III (according to EN 60 730)
IP 30 (according to EN 60 529)
CE-conformity, electromagnetic compatibility
according to EN 61 326, EMC directive 2014 ⁄ 30 ⁄ EU,
low voltage directive 2014 ⁄ 35 ⁄ EU
Traffic light display (five coloured LEDs, see table)
for indication of CO2 concentration
Plug-in power supply unit (connection cable approx. 1.5 m) or
Flush-mount power supply unit for installation on flush-mount socket
Stainless steel stand (RCO2-A NT ST)
Display
CO2
5 LEDs
5 LEDs
5 LEDs
Equipment
Plug-in power supply unit
Plug-in power supply unit, stainless steel stand
Flush-mount power supply unit
Rev. 2021 - V13
Item no.
(Baldur 1)
1501-61A0-7331-232
1501-61A0-7331-231
1501-61A0-7331-233
