G 100 / G 120
10.4

Electrical Schematic Components

wc_tx000998gb.fm
Ref. Description Ref.
1 Lug safety limit switch 16
2 Mechanical lugs 17
3 Plug 5 - current transformer 18
4 Plug 4 - line voltage inputs 19
5 Shunt 20
6 120V 20A GFI receptacle 21
7 120V breaker 22
8 240V 50A breaker 23
10 240V 50A receptacle 24
12 Engine control module 25
13 Main breaker 26
14 Bond bar 27
15 Voltage selector switch 28
Wire Colors
BLK Black RED Red ORN
GRN Green VIO Violet
BLU Blue WHT White
YEL Yellow BRN Brown
91
Description
Generator
Voltage regulator
Voltage adjustment rheostat
Terminal block
Exciter
Stator
Rotor
Rectifier
Rotor winding
Main stator windings
Auxiliary stator winding
Stator
Terminal strip
Orange
LT Light
