Generator Monitoring - Wacker Neuson G 100 Notice D'emploi

Operation
4.15

Generator Monitoring

Generator information is displayed on the top line of the LCD panel and is scrolled
continuously while the generator is operating, to show the voltage, amperage and
frequency of each phase.
Volts "V"- Displays the AC output voltage being produced by the generator.
Phase "Ø" - Indicates which leg is currently being displayed. In three-phase mode,
the display will read P1, P2, or P3. In single-phase mode, the display will read L1,
L3, or LL.
Amps "A" - Displays the AC output amperage produced by the generator. If the
generator is operating at no-load, output amperage will display a 0.
Hertz "Hz" - Displays output frequency. This gauge should read approximately 60
Hz under a no-load condition. If the frequency is too high, check the engine rpm.
HZ
Ø A
V
208 P1 24 61.5
85% 175 78 14.3
HZ
Ø A
V
READY
100% 175 0 13.2
Sample display with engine
running.
Sample display in "Auto"
mode.
