TURN THE AIR CONDITIONER OFF AND REMOVE THE PLUG FROM THE POWER OUTLET.
Air Filter Cleaning
The air filter should be checked at least twice a month to see if cleaning is necessary. Trapped
particles in the filter will build up and block the airflow. This reduces the cooling capacity and
also causes an accumulation of frost on the cooling evaporator. To clean the air filter:
1. Put your hands on the handle on the right hand side of the front grille then pull the air filter out, as
shown in FIG.14.
2. Wash the air filter under the faucet with warm water. Be sure to shake off all the water before replacing
the filter.
Air Conditioner Cleaning
Clean the front grille and inlet grille by wiping with a cloth dampened in mild detergent solution
shown in FIG.15.The cabinet may be washed with mild soap or detergent and lukewarm water, then polish
with liquid appliance wax.
To ensure continued peak efficiency, the condenser coils(outdoor side of the unit) should be checked
periodically and cleaned if they become clogged with soot or dirt. Brush or vacuum exterior coils to
remove debris from fins.
How to Remove the Front Grille
1. Remove the two screws securing the front grille.
2. Pull the grille up from the bottom and pull the top of the grille away from the case to lift the top tabs out
of their slots, as shown in FIG.16.

MAINTENANCE

FIG.14
FIG.15
??
as
,
FIG.16
