6
WIRING DIAGRAM
Order of wires on the terminal block may not be as shown.
There are typically three wires to be connected to an electrical fan; Load, Neutral and Ground. Load provides power to the fan, Neutral is for returning
current and closing the electrical circuit, and Ground is for an additional path to safely return current to the ground, in case of an accidental electrical
short in the fan and/or discharging of fan metal components.
Fantech radon fans are permanently connected appliances employing a reinforced polymeric construction. The non-conductive construction functions
as a "Double Insulated" protective System (Complies with Standard for Double Insulation Systems for Use in Electrical Equipment, UL 1097), thus
eliminating the need for a grounding conductor. All Fantech radon fans are tested and reviewed by Underwriter Laboratories, a 3rd party independent
safety governing body, and deemed suitable for outdoor use (Standard for Safety-Electric Fans, UL 507).
Please contact Fantech Technical Support if additional information is needed regarding this matter.
DIMENSIONS
B
A
B
C
15
7
7
14
/
15
/
13
/
16
8
8
All dimensions in inches.
Line IN (Black)
120V AC
Neutral (White)
C
fantech
A
D
E
1
1
5
/
6
/
2
8
Capacitor
Brown
Black
Blue
D
E
Fan Motor
