ADVANCED
Firmware Upgrade: device firmware upgrade. Supported only by
some RDNET devices.
Router Firmware Upgrade: RDNET CONTROL 2 unit firmware
upgrade.
HOW TO UPGRADE THE RDNET CONTROL 2 UNIT FIRMWARE
1.
Link the RDNET CONTROL 2 unit to the computer through the USB
cable and turn it on without connecting any device.
2. Wait until its front panel LEDs stop flashing .
In the software home page, select ADVANCED> Router Firmware
3.
Upgrade to open the respective window, then click LOAD and choose
the CONTROL2.RDU file.
4. The download automatically begins. A new window appears
reminding you to disconnect the USB cable and then reconnect it
later. Click OK when complete.
5. Await until the progress bar indicates the installation end, then
disconnect the USB cable and reconnect it later. The RDNET CONTROL
2 unit will automatically reboot.
MENU "?"
About: it opens a window indicating
the current software release.
USE IN "ON LINE" MODE
When online, the RDNET CONTROL 2 unit sequentially scans all devices,
which are automatically assigned to digital addresses.
The software synoptic is compared to the real settings and any difference
is pointed out: the device objects shown in the software without being
really present in the net have their "Comm" indicator red, while for the
remaining ones, it has to be checked if program equalization data is
synchronized with realdata;otherwise,"Eq.Sync" led remains off. Devices
linked to the net are automatically added to the software synoptic.
Therefore the software shows an object per each device that has been
found.
HOW TO UPGRADE
THE RDNET CONTROL 2
UNIT FIRMWARE
USE IN "ON LINE" MODE
