ASSEMBLY INSTRUCTIONS
1. Insert wood dowels (CC) and cam bolts (BB) into
both middle shelf moldings (K) and attach them to
the middle shelf (F), making sure the top edges are
flush. Secure into place with cam locks (AA).
Hardware Used
AA
Cam lock
BB Cam bolt
Wood dowel
CC
2. Insert wood dowels (CC) and cam bolts (BB) into
left upper side frame (B). Attach the assembled
middle shelf (F), back upper stretcher (I) and front
stretcher (H) to left upper side frame (B). Secure
into place with cam locks (AA).
Hardware Used
AA
Cam lock
BB
Cam bolt
Wood dowel
CC
3. Repeat the same procedure to attach right upper
side frame (D) at the opposite end.
Hardware Used
AA
Cam lock
BB
Cam bolt
CC Wood dowel
1
CC
K
x 4
x 4
x 4 F
2
H
F
AA
CC
x 7
x 7
x 2
Cam locks face
BB
B
back of the unit
3
BB
D
I
x 7
H
x 7
CC
x 2
AA
BB
5
ASSEMBLY INSTRUCTIONS
4. Insert wood dowels (CC) and cam bolts (BB) into the
AA top panel (A) and attach it to the previous assembly,
Secure into place with cam locks (AA).
Hardware Used
AA
Cam lock
BB
BB
Cam bolt
Wood dowel
CC
K
5. Align and attach bottom shelf (G) to the previous
assembly, using four 30 mm bolts (DD). Tighten with
the provided hex wrench (GG).
Hardware Used
I
DD 1/4" x 30 mm Bolt
AA
GG Hex wrench
BB
6. Insert wood dowels (CC) and cam bolts (BB)
into left lower side frame (C). Attach back middle
stretcher (J), back bottom stretcher (L) and front
stretcher (H) to left lower side frame (C). Secure
into place with cam locks (AA).
Hardware Used
AA
AA
Cam lock
BB
Cam bolt
CC Wood dowel
4
AA
BB
x 10
x 10
x 6
5
DD
x 4
x 1
G
6
H
L
AA
BB
C
x 5
CC
x 5
Cam locks face
x 1
BB
back of the unit
6
CC
A
I
J
AA
