In ON state:
1 click: To turn off the flashlight.
Press and hold: To start cycling through the modes of relevant Section.
The same in OFF & ON states:
2 clicks: To turn on Main mode [Section 2]. Another double click will
switch between chosen modes in [Section 1] and [Section 2].
3 clicks: To turn on Turbo mode [Section 3].
4 clicks: To turn on Strobe mode [Section 4].
Automemorizing. After switching off the last used mode is memorized
for quick access at next switching on.
Safe high brightness modes. Turbo modes give maximum brightness
until the temperature of the flashlight and discharge current of the
battery don't exceed critical values.
Digital Light Stabilization & Safe Soft-Start System allows to in-
crease runtime, get longer lifetime of rechargeable battery and protect
it from overdischarge or overheating.
Active temperature control. When the temperature of the flashlight
becomes close to +58 °С, brightness decreases to safe value, allowing
the flashlight to avoid overheating for a long period of time. In condi-
tions of good air-cooling the flashlight delivers light without stepping
down.
Warning indication shows the battery level and the temperature
inside the flashlight.
Low battery level. When battery level is approximately <25%, the color
LED will show the warning level by flashing orange once in 2 seconds.
With further voltage reduction brightness will start to decrease in steps
for safety of the battery and user. If brightness of the mode (except
Firefly modes and Main1) is approximately <25% from nominal value,
the main LED will flash 2 times. Critical battery level approximately
<10% is indicated by flashing red once a second.
High temperature. When the temperature increases to the warning
level, the color LED flashes orange 3 times once in 2 seconds. At critical
level it flashes red 3 times once in 1 second. Brightness starts to reduce
to safe level.
Lock-out function. Unscrew the tailcap to 1/4 for the protection from
accidental switching on. State Indication will be turned off.
Multicolor State Indication. Short flashes every 4 seconds show the
battery level even in OFF state (untill battery level becomes lower than
the critical one). The indication also helps to find the flashlight in the
dark.
Switching Multicolor State Indication ON/OFF. Multicolor State
Indication has 3 operating modes:
1. The indication is switched off in Firefly modes and in OFF state
(by default).
2. The indication is switched on in any state.
3. The indication is switched off in any state.
To change the operating mode, unscrew the tailcap to 1/4 while the
flashlight is off, press the button and keeping the button pressed
4 ENG USER MANUAL WIZARD C2 PRO MAX
tighten and unscrew the tailcap again. Indication operating modes will
switch cyclically. The settings will be memorized even when battery
is changed. Ultra-low current consumption allows color indication to
work for maximum period of time.
Warnings
For effective operation of the flashlight we recommend branded 21700
Li-Ion batteries. Also 18650 Li-Ion batteries no more than 70 mm long
with up to 18.7 mm diameter and permissible discharge current of at
least 15A can be used together with battery adapter.
The flashlight can get hot in Turbo modes, Strobe2 and Strobe3 quickly
and discharge the battery with high current. Don't leave it without your
attention as very bright light might heat objects and cause fire. It is
forbidden to charge the battery inside the flashlight when the ambient
temperature is below 0 °C.
1. Always follow the instructions from this manual and recommenda-
tions on battery usage.
2. Apply only the recommended power sources.
3. Do not reverse battery polarity.
4. Do not modify or recast the flashlight and its components as it will
deprive you of the warranty.
5. Do not allow water or any other liquid to leak into the flashlight.
6. Do not aim a switched-on flashlight at people's or animals' eyes — it
can cause temporary blindness.
7. Do not allow children to use the flashlight without your assistance.
The producer will not be liable for any harm done to the user if it
was caused by improper use of the product.

Care and Storage

It is recommended to clean the threads and O-rings off dirt and old
grease once or twice per year. Remember that reliable protection from
water and dust cannot be provided by worn out sealing. The fouling
as well as lack of lubricant cause fast wear-out of threads and sealing
rings.
