Current Measurement 10 A
• Position measurement function selection switch to A 10= or A 10~
measurement range.
• Connect the black test lead to the COM socket and the red test lead to the
10 A socket.
• Connect test leads to UUT.
• Read the measurement result displayed on the screen.

5.7 Temperature Measurement

Prior to any temperature measurement it has to be ensured that the
surface to be measures is not live. Failure to comply with this prescrip-
tion can lead to dangerous corporal user injuries or cause instrument
damage.
To avoid burns only touch UUT by means of the thermocouple.
• Position measurement function selection switch to °C - measurement range.
• Connect the minuspole of the probe to the COM socket and the pluspole of
the probe to the VΩmA socket.
• Connect temperature probe to UUT.
• Read the measurement result displayed on the screen.
Temperature Measurement
