Resistance Measurement

AC Voltage Measurement:
• Select measurement range V via measurement function selection switch.
• Connect the black test lead to the COM socket and the red test lead to the
VΩmA socket.
• Connect test leads to UUT.
• Read the measurement result displayed on the screen.
5.2 Resistance Measurement
Prior to any resistance measurement it has to be ensured that the resis-
tor to be tested is not live. Failure to comply with this prescription can
lead to dangerous corporal user injuries or cause instrument damage.
Additionally, foreign voltages falsify the measurement result.
• Select measurement range 2MΩ, 200kΩ, 20kΩ or 2000Ω via meas-
urement function selection switch.
• Connect the black test lead to the COM socket and the red test lead to the
VΩmA socket.
• Connect the test leads to UUT.
• Read the measurement result displayed on the screen.
30
