ENGLISH
6 OUTPUTS AND LED INDICATIONS
6.1 RELAY OPERATION MODE
The detector has a relay contact on each output. By means of a slide switch,
it is possible to select the dark current mode or the input continuous current
mode for each channel.
Switch
1
2
1
2
6.2 RELAY CONTACT STATE
The following table shows the relay state depending on the operation mode
selected and the detector state.
Detector state
Loop free
Loop engaged
Loop malfunction
Resetting
Current off
6.3 BEHAVIOUR IN CASE OF LOOP MALFUNCTION
In case of loop malfunction, the relay of the unusable channel moves to the
"loop engaged" state. The green Led goes off and the red Led comes on.
The detector channel starts operating autonomously after malfunction
elimination. At this point, the green Led is operated by impulse to signal
the malfunction occurred and corrected. By activating the reset key, the
malfunction indication disappears.

6.4 LED INDICATIONS

The green Led indicates that the detector channel is enabled for operation
and, through blinking light signals, provides important information on detector
activation (malfunction, setting, frequency emission).The red Led shows the
relay output activation according to the loop engagement state.
GREEN LED
Off
Blinking
Blinking after setting
On
On
Off
Impulse
Impulse

7) GENERAL TECHNICAL SPECIFICATIONS

Dimensions:
Power supply voltage:
Absorbed power:
Ambient temperature permitted:from -20°C to + 70°C
Preservation temperature:
Air humidity:
Loop inductance:
Frequency range:
Triggering sensitivity:
Holding time:
Loop cable:
Loop resistance:
Relay:
Signal time, impulse time:
Cycle time:
Response time:
6 -
RMM2 - Ver. 02
INSTALLATION MANUAL
Position Operation mode
Dark current mode (relay
coil at rest on signal emis-
sion).
right
Input continuous current
mode (relay coil in working
position on signal emission)
left
GREEN LED DETECTOR STATE
Resetting or no power
Off
supply
Off Setting
- Loop frequency emission
Off Detector ready, loop free
On Detector ready, loop engaged
On Loop malfunction
Loop free after temporary
Off
malfunction
Loop free after temporary
On
malfunction
76x38x71 (heightxwidthxlength) RAL
5005, with 11-pole round plug
230V ± 10%/-15%, 50/60 Hz
max. 2.5 VA
from -40°C to + 70°C
<95% (without condensation)
20-700 uH
30-130 kHz on two levels, common to the two
channels
0.01% up to 0.65% (∆f/f) on 4 levels for each
channel
0.02% up to 1.3% (∆L/L).
5 min. or continuous, common to the two
channels.
< 250 m
< 20 Ohm (including the cable)
Contact on closing 250 V a.c., 4A,
1000 W (Ohmic load AC).
Min. load on contacts: 10mV/1 uA.
Criterion for operating/dark current to be
chosen by means of selector.
Maximum electrical resistance:
coil-contact 4000V a.c.
contact-contact 1000V a.c.
> 200 ms
80 ms
160 ms
Limit speed for presence identification:
Direction identification:
Connection:
EC reference standards:
Other standards:
NOTES:
Always carry out installation and connections with the power supply off.
Follow the general instructions for installing and laying out the loop.
For full compliance with the current EMC regulations, the cable between
the detector and the loop must be screened: obviously, the loop laid out
underground does not require a screened cable.
Dimensions:
8) KEYS AND CONNECTIONS
Front view:
1
2
F
H 5min.
Service
Channel 1 loop condition/loop control
Channel 2 loop condition/loop control
1
Channel 1 criterion switch for operating/
2
dark current.
1 Channel 2 criterion switch for operating/
dark current.
2
Reset
Connections:
230V L 1
Note:
50-60Hz N
2
The relay contacts are illustrated without power supply!
Earth
9
3
2 Mixed low and minimum voltage operation is not
4
permitted on relays
5
1
(e.g. : 24 V d.c. on relay 1 and 230V a.c. on relay 2).
6
7
1
8
The relay contact time is increased by RC elements
10
connected in parallel
2
11
externally (ex. 100 Ohm/10n/F).
9)ASSEMBLY AND SETTING-UP INSTRUCTIONS
- The relays must not be operated on low voltage mixed with voltage lower
than 42V (ex. 24 Vdc on relay 1 and 230 Vac on relay 2).
- Connection cable insulation must be suitable for voltage of 230V.
- In order to set up the loop/detector system, select on the detector the set-
tings for presence recognition (dip switch 7 OFF) and continuous signal (dip
switch 8 OFF). By engaging the loop, the exact operation of the detector
and the relay outputs can be easily controlled. After carrying out this test
successfully, proceed to set the direction recognition and/or the impulse
signal emission.
- When selecting the frequency level for the loop of any adjacent detector,
a distance of about 15 kHz must be left between the frequencies.
100 km/h
90 km/h at 2 m from loop
45 km/h at 1 m from loop
11-pole round plug
EN 50082, part 2 Resistance to disturbance
(industrial sector)
EN 50081, part 1 Emission of disturbance
(domestic sector)
VDE 0160 Low voltage directive
Channel 1 sensitivity
Channel 2 sensitivity
High/low frequency
5 min/continuous holding time
On/off direction logic
Continuous signal/impulse signal
