32 | English
 Only insert one screwdriver bit per chamber into the bit magazine.
Use only short standard screwdriver bits. Longer screwdriver bits can-
not be loaded into the bit magazine.
– Turn the bit magazine 11 until an empty chamber can be seen in viewing
window 3.
– Push the sliding switch 7 toward the front.
– Insert the screwdriver bit 1 directly into the tool holder 2.
– Push the sliding switch 7 to the rear to load the screwdriver bit 1 into bit
magazine 11.
– As soon as you push the sliding switch 7 to the rear or actuate the On/Off
switch 10 when in the rear position, the bit magazine 11 is illuminated for
approx. 20 seconds.
Changing the Tool (see figure D)
 When changing the application tool, wear safety goggles. Do not
stare directly into the tool holder. When changing the tool insert, it can
be thrown out toward the front.
– Turn the bit magazine 11 until the desired screwdriver bit 1 can be seen
in viewing window 3.
– Push the sliding switch 7 toward the front.
Operation

Starting Operation

Reversing the rotational direction (see figure E)
The rotational direction switch 8 is used to reverse the rotational direction of
the machine. However, this is not possible with the On/Off switch 10 actuated.
Right rotation: For driving in screws, push the rotational direction switch 8
left to the stop.
The indicator for right rotation 4 lights up when the On/Off switch
10 is actuated and the motor is running.
Left Rotation: For loosening or unscrewing screws, push the rotational di-
rection switch 8 right to the stop.
The indicator for left rotation 6 lights up when the On/Off switch 10
is actuated and the motor is running.
