Installation instructions, only for experts
4.4. Connection diagram
Fig. 5
Connection diagram for the Concept R mini 3.5 kW, 4.5 kW and 6.0 kW
(CP-RM-35 / CP-RM-45 / CR-RM-60)
4
400 V~
3x16 A
1 Sauna control unit
2 Temperature sensor with excess temperature controller
3 Sauna heater
4 Power supply
WORLD OF WELLNESS
1
L2 L2
L3
N
N
U V
W
N
U V
W
3
9 kW
10,5 kW
p. 14/24
r r
w
w
ϑ
ϑ
2
