Installation instructions, only for experts

5. Connection diagram

7
6
1 Excess temperature fuse
2 Temperature sensor
3 Terminal strip of the heater sensor
4 Safety shut-off
WORLD OF WELLNESS
5
red
STRG
white
white
red
4
5 Terminal for the temperature sensor
6 Terminal for the excess tempera-
ture fuse
7 Sauna control unit
p. 14/18
1
2
3
red
STRG
