aintenance and cleaning
For safety reasons before carrying out any maintenance or cleaning
operation, switch off the unit turning the selection switch to "Stop" and
the power supply switch on position 0 (OFF).
Maintenance
Maintenance must only be carried out by an assistance
centre authorised by the manufacturer or by qualified
personnel
Be careful during any maintenance operation; you could get injured by
some metal parts; use protective gloves.
The units do not require any particular maintenance operation: only
the periodical cleaning of the air filter should be carried out.
It is necessary to carry out a running in period of 100 hours in order to
eliminate all mechanical friction.
The starting up must be carried out at the maximum speed.
For good operation of the units follow the instructions below:
! keep the air filter clean;
! do not pour liquids into the unit;
! do not introduce metal parts through the air outlet grill.
! keep the air inlet and outlet free at all times.
Each time the machine is turned on after being idle for a long
period, ensure there is no air in the heat exchanger.
Before using the unit for air conditioning, check that:
! condensate drainage is performed correctly:
! the heat exchanger fins are not obstructed by deposits of dirt.
If necessary clean the fins with low pressure compressed air
or steam without damaging the fins.
Cleaning
The filter must only be cleaned by an assistance centre
authorised by the manufacturer or by qualified personnel
Clean the filter at least once a month and in any case before using the
unit (before the heating or the air conditioning season).
For cleaning the air filter proceed as follows (figure 7)
model FWV and FWZ
!
turn the screws that secure the filter to the cover cabinet 90° and
remove the filter,
model FWL and FWR
!
remove the air filters that are inside the intake grids located on the
front panel of the cover cabinet,
concealed model FWM and FWS
!
reach the unit through the inspection panel and remove the filter,
turning the locking brackets 90°,
clean the filter with lukewarm water, or in case of dry dust, clean
!
the filter with compressed air,
reassemble the filter after having it dried up.
!
It is recommended to replace the air filter yearly, and to use original
spare parts. The unit model name is stated on the nameplate located
on the side panel of the basic unit.
To clean the unit cabinet proceed as follows:
! use a soft cloth;
! do not pour any liquid on the unit, as this could cause electrical
shocks or damage the components inside it;
! do not use any aggressive chemical solvents; do not use very
hot water to clean the air outlet grill.
Installation and operation manual
3
d
isposal reqUirements
Dismantling of the unit should be done in accordance with the relevant
local and national legislation.
t
roUBleshooting
If the unit does not work properly first check the points reported in the
table below before requesting service. If the problem cannot be solved
contact your dealer or service centre.
Symptom 1: The unit does not run at all
P
ossible causes
Power failure
Leakage breaker tripped
The switch is on STOP ("0") position
Symptom 2: Poor cooling or heating performance
P
ossible causes
Dirty or clogged air filter
Obstacle near the air inlet or outlet
Air inside the heat exchanger
Doors and windows are open
The unit is running at low speed
Symptom 3: The unit leaks
P
ossible causes
The unit is not levelled
Drip tray is clogged
Units are marked with the following symbol:
This means that electrical and electronic products may not
be mixed with unsorted household waste.
Do NOT try to dismantle the system yourself: the
dismantling of the system, treatment of the refrigerant, of
oil and of other parts must be done by an authorized
installer and must comply with applicable legislation.
Units must be treated at a specialized treatment facility for reuse,
recycling and recovery.
By ensuring this product is disposed of correctly, you will help to
prevent potential negative consequences for the environment and
human health.
For more information, contact your installer or local authority.
c
orrective action
Restore power
Contact service centre
Turn ON the unit, select "I"
c
orrective action
Clean the air filter
Remove the obstacle
Contact the installer
Close doors and windows
Select medium or high fan speed
c
orrective action
Contact the installer
Contact the installer
FWV+FWZ+FWL+FWR+FWM+FWS
Fan coil units
4PW17548-5
