INSTALLATION
INSTALLATION / INSTALLATION
RCZ66LT
RCZ66TA
RCZ66IR
PIÈCES / PARTS
Liste complète des pièces pour l'assemblage de votre valve
thermostatique.
Complete parts list for installing your thermostatic valve.
LISTE DES PIÈCES / PARTS LIST
01 Robinet de douche / Shower mixer
02 Pièces de branchement / Rough parts
03 Douchette / Handshower
04 Crochet coulissant / Slider
05 Barre verticale avec ou sans mists / Vertical bar with or without mists
06 Tuyau flexible / Flexible hose
07
08
07 Support murale / Wall support bracket
08 Fixation murale / Wall mount bracket
09 Barre horizontale avec ou sans mists /
Horizontal bar with or without mists
10 Tête pluie / Showerhead (RCZ66IR)
03
RCZ66IR
10
04
06
02
01
Doc. # DR069-4 / 24-08-2021
ÉTAPES / STEPS
DR068
01
Installez les raccords selon les instructions
fournies dans la boîte de ceux-ci.
Install the fittings according to the instructions
provided in the fitting box.
05
Serrez les vis allen sous les 2 raccords en
09
prennant soin de bien aligner les brides
murales puis refermez .
Aligning the wall flanges and tighten the allen
screws under both fittings.
05
02
03
Enlevez les bouchons et les protecteurs de
Appliquez du silicone pour étancher le trou de
joints toriques.
passage du raccord et positionnez les brides
murales.
Remove the caps and the o-ring protective
sleeves.
Apply silicone to seal the hole of the fittings and
position the wall flanges.
06
07
Assemblez les barres verticales et horizon-
Glissez le crochet coulissant sur la barre
tales.
verticale.
Assemble horizontal and vertical bars.
Slide the sliding hook onto the vertical bar.
ENSEMBLE DE DOUCHE COZI / COZI SHOWER PIPE
04
Assurez-vous que la poignée du dessus soit
ouverte. Attention retirer les 2 vis allen sous
les raccords de la valve avant l'installation.
Insérez la valve sur les raccords délicatement
en glissant bien sur le joints toriques.
Make sure the top handle is in open position. At-
tention remove the 2 allen screws under the valve
connections before installation. Insert the valve
on the fittings gently by sliding on the O-rings.
08
Positionnez la barre verticale sur la barre
verticale sur la valve sans la serrer.
Position the vertical bar on the valve without
tightening it.
www.rubi.ca - 1.888.988.RUBI (7824)
- RCZ66
OUVRIR / OPEN
