Martellato Chocobig EVOLUTION CHOCOBIGEV Notice Technique page 28

DESCRIPTION
N Engine oil seal
Q Perimeter seal
Remove the first oil seal.
Take a new oil seal
Paying attention
to the orientation
For other electrical or mechanical parts contact the Martellato
28
Every 150~ working hours replace the motor oil seal (N)
supplied with the fountain.
Contact the supplier on anything needed.
CODE
CHOCOGM
CHOCOGV
Raise the oil seal to be replaced with a screwdriver
Place the new oil seal using the
flat end of a screwdriver to fix it
commercial network or your supplier.
CHBG00EV - ENGLISH
perfectly
N
Q
Position the second oil seal.
Paying attention
to the orientation
Make sure the black perimeter seal
(Q) is correctly inserted before
screwing the fountain bowl.
