Installing your instrument

Power requirements

Characteristic
Power source voltage
Power source frequency
Power consumption

Input signal requirements

Keep the input signals within allowed limits to ensure the most accurate measurements and prevent damage to the analog and
digital probes or instrument.
Make sure that input signals connected to the LPD64 instrument are within the following requirements.
Input
Analog input channels, 50 Ω, maximum input
voltage at SMA connector
Ref In maximum input voltage at BNC (rear panel) 7 V
Aux In trigger input, 50 Ω, maximum input voltage
at SMA connector

Installing the instrument in a rack

Use these instructions to install the Low Profile instrument into a standard 19" wide by 24" to 32" deep equipment rack.
The instrument comes equipped with the rack bracket hardware installed on the chassis. Use the bolts and washers from the bag
that ships with the instrument to install the rear rack brackets in the rack.
To use an Low Profile instrument on a bench, purchase and install the MSO58LP/LPD64 Benchtop Conversion kit (Tektronix part
number 020-3180-xx). The kit includes chassis feet and a handle, and lets you stack instruments on a bench.
Follow these steps to install the instrument in a rack:
2
Description
100 V - 240 V
, ±10%, single phase
AC RMS
50/60 Hz, 100-240 V
400 Hz, 115 V
All models: 360 W maximum
Description
5 V
RMS
Transient Overvoltage is 0 V. The measuring terminals on this product are
not rated for connection to mains or Category II, III, or IV circuits.
PP
±5 V
RMS
LPD64 Installation and Safety Manual
