Technical description

6 Technical description
6.1

Function description

The camera is located in an aluminium case and transfers the image via a cable to a monitor. The
built-in infrared LEDs improve night vision.
The camera consists of the following elements:
No. in
fig. 4, page 3
1
2
3
4
5
7

General instructions for electrical connection

7.1 Laying cables
A
NOTICE!
The cables may not be exposed for long periods to solvents such as benzene, since
they can damage the cable.
I
NOTE
•
As far as possible, use original ducts for laying the cables, or other suitable options
such as paneling edges, ventilation grills or dummy plugs. If no openings are avail-
able, you must drill holes for the cables. Check beforehand that there is sufficient
space on the other side for the drill head to emerge.
•
Cables and connections that are not properly installed will cause malfunctions or
damage to components. Correct installation of cables and connections ensures
lasting and trouble-free operation of the retrofitted components.
10
Description
Infrared LEDs
Sleeve
6-pin connection cable
Plug
LDR sensor
PerfectView
