DIMENSIONS FOR MODELS 6OHK-SS SOLID DOOR
11 ⁄ "
15
16
(30.3cm)
12 ⁄ "
1
4
(31.1cm)
33 ⁄ " to 34 ⁄ "
3 3
4 4
(85.7 to 88.3cm)
RECOMMENDED ROUGH IN OPENING DIMENSIONS, 6OHK-SS SOLID DOOR
(86.4 to 88.9cm)
26 ⁄ "
7
16
(67.2cm)
23 ⁄ "
3" to 4"
7
8
(60.7cm) (7.6 to 10.2cm)
** 34" to 35"
*24" (61 cm)
standard cabinet
depth
24" (61 cm)
47"
(119.4cm)
22"
(55.9cm)
24 ⁄ "
5
16
(61.8cm)
26 ⁄ "
3
4
(68.0cm)
Electrical Requirements: A grounded 115 volt,
15 amp dedicated circuit is required. A GFCI
receptacle may be required for outdoor units.
Power outlet can be located in the back wall
behind unit. Add 1" to depth for thickness of
plug, or recess outlet 1" into the wall. Power
outlet can also be installed in adjacent cabi-
netry with a cutout for routing of power cord.
Follow all local building codes when installing
electrical and unit.
Product weight = 140 lbs. (63.6 kg.)
* Depth dimension may vary depending on
each individual installation.
** Minimum rough in opening required is to be
larger than the adjusted height of the cabinet.
15
11"
(27.9cm)
